AASHTO M249 Thermoplastic Pavement Marking Paint With Glass Bead

Product Details:
Place of Origin: Guangxi
Brand Name: LUHU
Certification: ISO
Model Number: LH-TL-14
Payment & Shipping Terms:
Minimum Order Quantity: 3TONS
Price: Negotiable
Packaging Details: 25kg/bag, one 20ft container can be loaded with 28tons
Delivery Time: 3-7working days
Payment Terms: T/T, Western Union
Supply Ability: 1000000tons/year
  • Detail Information
  • Product Description

Detail Information

Ingredient: C5 Petropols, EVA, PE Wax, Titanium Dioxide, Filler Materials Appearance: Powder
Color: White&Yellow Weight: 25kg/bag
Heating Temperature: 180-200°C Shelf Life: 12 Months
Type: >35% Premixed Glass Beads
High Light:

M249 Thermoplastic Pavement Marking Paint


AASHTO Thermoplastic Pavement Marking Paint


C5 Petropols High Reflective Traffic Paint

Product Description

AASHTO M249 Thermoplastic Pavement Marking High Refelctive Traffic Paint with Glass Bead


Product Description


Thermoplastic road marking paint consists of resin,EVA,PE wax ,fillers materials,glass bead,which is solid powder condition at normal temperature,If is is heated to 180-200 degrees by heat fusing pot under construction,it will appears flowage, coating pot under construction, it will appears flowage, coating the paint to the road surface will form hard film,It has full line type,strong wearing resistance and other flowage, Sprinkling reflecting glass micro beads on the surface under construction, it has good reflecting effect at night , it is widely applied in highway and road,According to the environment used and the different construction requirements,we can supply different types of paint for our customer option.



Application:Mark on the Road with effects of guidance and Warn
Type:Great Reflective Thermoplastic (≥35% Premixed Glass Beads)
Ingredient:C5 Petropols, EVA, PE wax, titanium dioxide, filler materials
Color:White & Yellow
Heating Temperature:180-200°C
Touch/ Full Dry Time After Marking:3/10 mins
Shelf Life:12 months
1.Great Reflective
2.Excellent Durability and Strong Adhension Power
3.High Dirty Pick-up Resistance
4.High Usage Ratio and Save Cost of Gas
5.Bright Color and Not Fade Easily


AASHTO M249 Thermoplastic Pavement Marking Paint With Glass Bead 0


• The binder is resin or rosin and plasticizer that hold all ingredients together.
• The pigment supplies the color.
• Glass beads with the pigment provide the retro-reflectivity and visibility.
• Filler material provides the bulk.




Strong adhesion strength:Resin content is reasonable , and it was added special rubber elastomer in the primer in the primer , so it has strong adhesion strength, if the construction technique is reasonable, there is no peeling off.


Good cracking resistance:Thermoplastic line marking is easy to form crack because of the temperature variation of thermoplastic line marking.

Bright color:The paint adopts the color of the highest level with reasonable proportion, so it has good weather resistance and will not change color if long term exposure.


High usage ratio:The major feature of paint is low density , big volume and high usage ratio.


Good dirt resistance:The dosage and quality of PE wax are the key point of impacting the dirt resistance.PEwax of Exxon is our first choice for many years.




AASHTO M249 Thermoplastic Pavement Marking Paint With Glass Bead 1





Established in 2008, GZ LUHU TRAFFIC FACILITIES CO., LTD specializes in the the R&D, sales and engineering installation of traffic facilities.



It formed an alliance with Brother Guidepost, and established the brand LUHU and focused on the export of road marking paint and machine.


LUHU now has a number of experienced marking construction teams, with an annual construction line of 500,000 square meters.





AASHTO M249 Thermoplastic Pavement Marking Paint With Glass Bead 2


  • Short Lead Time with the Support of Factory (3-4days)
  • Convenient Transport (Guangzhou Port)
  • Competitive Price
  • Rich Experiences in Road Marking Services (annual marking: one million sqms)
  • Professional Road Marking Experts Can Demonstrate How to Operate Machines
  • Always Put People's Safety First



AASHTO M249 Thermoplastic Pavement Marking Paint With Glass Bead 3




AASHTO M249 Thermoplastic Pavement Marking Paint With Glass Bead 4AASHTO M249 Thermoplastic Pavement Marking Paint With Glass Bead 5




Q: What is the shelf life of thermoplastic paint?

A: Gradually the paint can be stored for one year in a dry condition.


Q: How long can the line keep after I apply the paint?

A: Gradually it can keep one to two years after marking, but it also depends on the construction and the traffic.

Q: For one ton of paint, how many square meters can be marked?

A: For concrete road, one ton of paint can mark 200 square meters with 1.8-2.0mm thickness; for asphalt, it can mark 180 square meters.





AASHTO M249 Thermoplastic Pavement Marking Paint With Glass Bead 6
