Home > products > Thermoplastic Road Marking Paint > C5 Resin Thermoplastic Road Marking Paint AASHTO M249 25kg/bag

C5 Resin Thermoplastic Road Marking Paint AASHTO M249 25kg/bag

Product Details

Place of Origin: China

Brand Name: HUAQUN

Certification: ISO 9001 , MSDS

Model Number: HQ

Payment & Shipping Terms

Minimum Order Quantity: 1 bag

Price: Negotiable

Packaging Details: 25kg per bag, 60 bags per pallets /jumbo bag

Delivery Time: 2-5 working days

Payment Terms: L/C, T/T

Supply Ability: 50 ton per day

Get Best Price
Highlight:

C5 Resin Thermoplastic Road Marking Paint

,

Thermoplastic Road Marking Paint AASHTO M249

Material:
C5 Resin
Color:
White , Yellow , Blue ,Green ,Red
Application Temperature:
180~220℃
Package:
25kg/bag
Theoretical Spreading Rate:
1000kg/200 Square Meters
Drying Time:
Less 3mins
Type:
Powder
Soft Point:
90~125℃
Material:
C5 Resin
Color:
White , Yellow , Blue ,Green ,Red
Application Temperature:
180~220℃
Package:
25kg/bag
Theoretical Spreading Rate:
1000kg/200 Square Meters
Drying Time:
Less 3mins
Type:
Powder
Soft Point:
90~125℃
C5 Resin Thermoplastic Road Marking Paint AASHTO M249 25kg/bag

Reflective Powder Road Line Marking Thermoplastic Road Marking Paint Standard AASHTO M 249 Standard For Road Marking



AASHTO Standard
Components Specification Test Result
Resin ≥20% 25%
Titanium Dioxide ≥10% 11%
Glass Beads

≥30%

33%







Thermoplastic road marking material is with advantages of fast dry, easy execute, high reflection, and long service life.

Thermoplastic marking paint is mainly used on road and highways. The thickness of this marking paint is (1.0 ~ 2.5) mm. The paint is mixed with reflective glass beads, or drop on reflective glass beads while marking construction. This kind of marking line has good night-time reflective performance and long service life. It is estimated according to the demand for various road marking coatings for the construction of large highways with traffic flow. It depends on the quality of the coating itself and generally can reach 2 ~ 3 years. The application of thermoplastic paint requires special heating equipment. When repainting the old marking line, the thicker old coating must be removed before applying.



Main Materials:



1.Titanium dioxide : Good whiteness, high purity, small particle size, low oil absorption.



2.C5 resin: Outstanding affinity for pigments , good compatibility with EVA , good heat stability.



3.PE wax: Heat resistance , abrasion resistance, as a lubricant, increase paint processing performance.



4.Calcium carbonate: High precise classification, high whiteness.



5.Glass beads: Drop on glass beads , intermix glass bead , we use top brand beads brand , high reflective.



Technical Data
Product Thermoplastic Road Marking Paint
Appearance Powder
Color White,yellow, or customied
Main Raw Material Pertroleum resin
Intermix glass bead content 30%
Application temperature 180~220
Soft point 90~125
Dry speed ≤3 min (23)
Theoretical Spreading rate 4-5 kg/square meter
Luminace factor White:≥75%, yellow:≥45%
Application Method Screeding, spray, extrusion, structural
Storage Dry, cool, avoid direct sunlight
Package  25kg per bag , 60bags per pallets







Features



Strong adhesion strength : Resin content is reasonable , and it was added special rubber elastomer in the primer in the primer , so it has strong adhesion strength, if the construction technique is reasonable, no peeling off.



Good cracking resistance : Thermoplastic Paint marking is cracking resistance than normal paint.



Bright color : The paint adopts the color of the highest level with reasonable proportion, so it has good weather resistance and will not change color if long term exposure.



High usage ratio : The major feature of paint is low density , big volume and high usage ratio.



Good dirt resistance : The dosage and quality of PE wax are the key point of impacting the dirt resistance.
