| MOQ: | 1 ton |
| Price: | Negotiable |
| Standard Packaging: | 25kgs/bag |
| Delivery Period: | 3-7 work days |
| Payment Method: | L/C, T/T, Western Union, MoneyGram |
| Supply Capacity: | 50 tons per day |
Good Leveling Thermoplastic Road Marking Paint 15% Premixed Glass Beads Eco-Friendly
Description
Hot melt reflective thermoplastic road marking paint powder:
Thermoplastic road marking paint consists of resin, EVA, PE wax, fillers materials, glass bead, which is solid powder condition at normal temperature, If is is heated to 180-200 degrees by heat fusing pot under construction, it will appears flowage, coating pot under construction, it will appears flowage, coating the paint to the road surface will form hard film,It has full line type,strong wearing resistance and other flowage, Sprinkling reflecting glass micro beads on the surface under construction, it has good reflecting effect at night , it is widely applied in highway and road. According to the environment used and the different construction requirements,we can supply different types of paint for our customer option.
Technical Specification
|
Density(g/cm3) |
1.8-2.3 |
| Softening point (℃) | 90-125 |
| Compressive Strength(MPa) | ≥12 |
| Glass bead content(%) | 0-30% |
| Liquidity | 35±10 |
| Packing | 25kg/bag |
| Color | White/Yellow/Blue/Red/Green/Customized |
| Executive standard | JT/T280-2004/AASHTO/BS3262/Customized |
| Appearance | Powder |
| Construction temperature | 180℃-220℃ |
| Whiteness | 70-85(Customized) |
| Inverse coefficient | 50-550 |
| Warranty | 12 months |
| Storage Method | Avoid light and moisture |
| Packing Size | 45×70×5CM |
ADVANTAGE OF THERMOPLASTIC PAINT
Hot-melt road marking coating uses the thermoplasticity of synthetic resin to make the hot-melt coating have quick-drying property, and the hot-melt property of synthetic resin is used to make the marking and pavement firmly bonded. Hot melt reflective road marking coatings are generally composed of thermoplastic resins, fillers, reflective materials and other additives. Hot melt coatings are powdery at room temperature. There is no solvent volatile component in the composition. It is melted by construction heating, then coated on the ground with specialized equipment and solidified into a film by physical cold condensation. For hot melt road coating, its fluidity is a very important technical index in the construction process.
CUSTOMIZED FORMULA
| Customized Formula | ||
| Customized Formula | Content(Customized range) | Characteristics |
| C5 Resin | 10%-22% | Fluidity Toughness Hardness Adhesion |
| Titanium Dioxide | 0.5-10% | 0.5%-30% |
| Premixed glass beads | 0%-30% | Reflective after surface wear |
| Calcium Carbonate Sand | 30%-80% | Whiteness Wear-resistant Hardness |
| PE Wax | 1%-1.5% | Cold and heat resistant |
| EVA | 0.5%-1% | Crack resistance |
| Plasticizer | 1%-1.5% | Toughness |
Components of Thermoplastic Paint
1. C5 Resin: good adhesion and flow, wear resistance, road line bright colors
2. Calcium Carbonate Powder: better whiteness, good pressure resistance and wear resistance
3. Premixed Glass Beads: Good retro-reflective function, long-lasting reflective effect
4. PE Wax:Excellent cold resistance, heat resistance, chemical resistance, abrasion
5. Titanium Dioxide: Best performing white pigment, good whiteness and weather resistance, high reflection coefficient
6. Quartz Sand: High temperature resistance, low coefficient of thermal expansion, high insulation, corrosion resistance
