Hand Push Thermoplastic Road Marking Machine with High Capacity 100kg Tanks and Plug-in Manually Mixer Devices

Product Introduction

A thermoplastic road marking machine is a device used to apply thermoplastic markings on roads.

Thermoplastic material is a kind of plastic that becomes soft and fluid when heated and solidifies when cooled. The machine heats the thermoplastic material to a molten state and then applies it through a nozzle or other applicator onto the road surface in the desired pattern, such as lane lines, crosswalks, arrows, etc.

These machines usually have a heating system to keep the thermoplastic at the proper temperature for application. They also have a mechanism for controlling the flow rate and spray pattern to ensure accurate and consistent markings. They play a crucial role in road construction and maintenance to enhance traffic safety and guidance.

Road Marking Machine

1. Torches

2. Trunk

3. Stirring Shaft

4. Paint Input Door

5. Stainless Steel Heat Perservation Kettle

6. Paint Outdput Door

7. Pointing Needle

8. Hanger & Front Burner

9. Landing Knife

10. Rear Burner

11. Marking Mold

12. Glass Beads Spreader

13. Glass Beads Box

14. Marking Mould Handle

15. Paint Output Handle

Specification:

●Insulation barrel: double-layer stainless steel insulation heating barrel, double-layer stainless steel bottom, 100 kg capacity,vertical manual mixing device, and removable barrel design.

●Glass bead storage tank: 10 kg/ box
●Adjustable glass bead seeder:synchronous clutch seeder, with speed regulating and shifting device. Adjustable width 50-200 mm
●Scoring bucket: it is made of high-precision ultra-thin material and has a scraper structure. It adopts a single scoring bucket handle. The knife is closed without material leakage. The marking edges are aligned, the head and tail are aligned, and the thickness is uniform.
●Floor cutter: hard alloy, with eccentric sleeve device, which can adjust the marking thickness range: 1-2.5 mm.
●Rubber wheel: aluminum
alloy wheel stock, special heat-resistant rubber, and the rear wheel is equipped with a positioner to ensure a straight line.
●Positioner: the rear tail wheel is equipped with a positioner to ensure that the vehicle body can walk in a straight line or turn freely
●Marking width: the standard configuration is 150mm, with different specifications such as
50/100/150/200/250/300/400/450mm. The marking bucket and glass bead spreader of different specifications can be replaced according to the engineering requirements

Feature:

This machine has the advantage of high-construction, fast, flexible operation, convenient maintenance and so on.

Application Area:

Highway, municipal roads, village or town road, guiding arrows words parking lines, factories etc.

Application:

Here are the general steps to operate a thermoplastic road - marking machine:

Preparation

- Inspect the machine: Check the thermoplastic road - marking machine thoroughly before use. Ensure that all parts such as the heating system, material - feeding system, and spraying or extrusion device are in good working condition.
- Material loading: Load the thermoplastic material into the machine's hopper. The material is usually in pellet or powder form. Make sure the material is of good quality and free from contaminants.
- Heating the material: Turn on the heating system of the machine to heat the thermoplastic material to its melting point. The melting temperature typically ranges from about 180 - 220 degrees Celsius, depending on the specific material formula. During the heating process, stir the material as needed to ensure even heating.

Marking operation

- Positioning: Move the road - marking machine to the starting point of the area to be marked on the road. Use appropriate positioning tools or markings on the road surface to ensure accurate placement of the first line of the marking.
- Set parameters: Adjust the width and thickness of the marking according to the design requirements. For example, the width of a normal traffic lane marking may be 10 - 15 cm, and the thickness is usually around 1.5 - 2.5 mm.
- Start marking: Start the material - feeding and spraying or extrusion mechanism of the machine. Slowly move the machine along the planned marking path at a constant speed. The speed of movement should be coordinated with the material output rate to ensure a uniform and continuous marking. As the thermoplastic material is applied to the road surface, it cools and solidifies quickly to form the marking.

Post - operation

- Clean - up: After the marking work is completed, turn off the heating system and allow the remaining material in the machine to cool slightly. Then, clean the machine's material - feeding system, spraying nozzles, and other parts to prevent the material from solidifying and clogging the equipment.
- Quality inspection: Inspect the completed road markings for quality. Check for any irregularities in width, thickness, and continuity. Also, ensure that the markings have good adhesion to the road surface and satisfactory reflectivity (if reflective materials such as glass beads are added).
